Emlid REACH RS2+

Currently not available in Canada due to certification process

Multi-band RTK GNSS receiver with centimeter precision

For surveying, mapping and navigation. Comes with a mobile app.

GNSS

GPS/QZSS L1C/A, L2C,
GLONASS L1OF, L2OF,
BeiDou B1I, B2I,
Galileo E1-B/C, E5b

Long range radio

LoRa 868/915 MHz, range up to 8

16 hrs as LTE RTK rover

LiFePO4 battery, 6–40V input, USB Type-C charging

Wi-Fi and Bluetooth

For connection with other devices

Specifications

• Mechanical

  Dimensions: 126 x 126 x 142  mm

  Weight: 950 g

  Operating tº: -20 to +65 ºC

  Ingress protection: IP67

• Electrical

  Autonomy: 16 hrs as LTE RTK rover, 22 hrs logging

  Battery: LiFePO4 6400 mAh, 6.4 V

  External power input: 6–40 V

  Charging: USB Type-C 5 V, 3 A

  Certification: FCC, CE

• Positioning

  Static: H: 4 mm + 0.5 ppm | V: 8 mm + 1 ppm

  PPK: H: 5 mm + 0.5 ppm | V: 10 mm + 1 ppm

  RTK: H: 7 mm + 1 ppm | V: 14 mm + 1 ppm

  Convergence time: ~5 s typically

• Connectivity

  LoRa radio

  Frequency range: 868/915 MHz

  Power: 0.1 W

  Distance: Up to 8 km

  LTE modem

  Regions: Global

  Bands: FDD-LTE: 1,2,3,4,5,7, 8, 12, 13, 18, 19, 20, 26, 28, 66 TD-LTE: 38,40,41
  UMTS (WCDMA/FDD): 1,3,2,4,5,6, 8,19 Quad-band, 850/1900, 900/1800 MHz

  SIM card: Nano-SIM

  Wi-Fi: 802.11 b/g/n

  Bluetooth: 4.0/2.1 EDR

  Ports: RS-232, USB Type-C

• Data

  Corrections: NTRIP, RTCM3

  Position output: NMEA, LLH/XYZ

  Data logging: RINEX

  Internal storage: 16 GB, 160+ days of logging at 1 Hz

• GNSS

  Signal tracked: GPS/QZSS L1C/A, L2C GLONASS L1OF, L2OF BeiDou B1I, B2I Galileo E1-B/C, E5b

  Number of channels: 184

  Update rates: up to 10 Hz
