Inspired Flight - IF1200A Aircraft Bundle

Inspired FlightSKU: B-1200A-BLUEUAS

Bundle: No Payload - BlueUAS Bundle
Price:
Sale price$51,097.50 CAD
Stock:
Backordered (usually ships in 2-4 weeks)

Description

Inspired Flight - IF1200A


Elevate Your Mission with the IF1200A - HEAVY-LIFT UAS

In the Box

BLUEUAS BUNDLE

  • IF1200A
  • 6 Folding Propellers
  • 2 Spare Folding Propellers
  • TA3000 Battery Charger
  • 16Ah Compact Smart Battery 44.4V, 12S (Includes: 2 16AH Compact batteries)
  • 1 JETI DS-12
  • 1 RFD 900X-US
  • 1 Encrypted Ruggedized Laptop Ground Station
  • 1 Rugged Transport Case

HERELINK BUNDLE

  • IF1200A
  • 6 Folding Propellers
  • 2 Spare Folding Propellers
  • TA3000 Battery Charger
  • 16Ah Compact Smart Battery 44.4V 12S (Includes: 2 16AH Compact batteries)
  • 1 Blue Herelink or Black Herelink Ground Controller
  • 1 Rugged Transport Case

Sony A7R Payload Option Includes:

  • Sony A7R 61MP camera
  • 35MM Lens
  • Gremsy gimbal

WWE Payload Option Includes:

  • Workswell Enterprise Thermal 16MPX Camera
  • Pixy WE gimbal
  • Quick Disconnect
  • 1 Damping Plate

Unrivaled Endurance. Limitless Possibilities.

  • 43min Max Flight Time

  • 19.1lbs Max Payload

  • 56mph Max Speed

  • 23knots Max Wind Resistance

Key features

Dual Propeller System

With larger, overlapping propellers, the aircraft retains a more compact frame. The alternating clockwise and counterclockwise propeller configuration increases the aircraft’s efficiency.

Dual Latching GPS Structure

Two GPS units ensure accuracy while also functioning as a convenient carrying handle when batteries are not installed.

SAFE drone™

In the event of a motor failure, the IF1200A will seamlessly transition to a secure manual flying mode & swiftly alert the operator to initiate an immediate landing.

Integrated Remote ID

Integrated Remote ID for out of the box FAA-Compliance.

HD FPV camera

Elevate your visual experience with the IF1200A HD FPV camera. Navigate aerial mapping, photogrammetry missions, utility inspections, and more with unparalleled clarity and precision.

Universal Payload Interface

Facilitates communication between the payload, ground control, and the flight controller, streamlining your workflow and optimizing productivity across virtually any mission.

The IF1200A offers a variety of pre-integrated payloads chosen specifically for each industry.

  • Optical
  • EO/IR
  • LiDAR

Empowering Mission Success Through Adaptive Design

Engineered with the end-user in mind, the IF1200A features an open interface and long flight times, enabling you to conquer missions across diverse domains.

  • Military
  • Mapping
  • Inspection
  • Emergency Response

Category-leading flight times and an optimal user experience make the IF1200A the heavy-lift platform of choice for the most risk-averse operators in North America.

Not just an aircraft, the IF1200A has numerous fully integrated payloads. Tightly integrated sensors allow operators to efficiently and safely get their job done, driving large increases in operational efficiency and cost savings over the impressive 5+ year projected lifetime of the system.

The SAFE droneTM capability allows the IF1200A to maintain safe and controlled flights, even in the extremely unlikely event of a motor failure. The IF1200A is able to alert the operator to land immediately and remain in a safe manual flying configuration, providing the ultimate piece of mind to operators with valuable payloads and/or underlying assets.

100% manufactured and supported in San Luis Obispo, CA, USA the IF1200A will be the ultimate tool for your enterprise in support of a variety of industrial applications.

Specifications

Performance

Max Ascent Speed 5 m/s 16.4 ft/s
Max Descent Speed 2.5 m/s 8.2 ft/s
Max Air Speed 25 m/s 56 mph
Max Wind Resistance 12 m/s, 15 m/s gusts 23 knots, 29 knot gusts
Max Tilt Angle 30°
Max Angular Velocity Tilt: 300°/s, Yaw: 45°/s
Operating Temperature -10°C ~ 40°C 14°F ~ 104°F
Operating Humidity 10% ~ 95%
Service Ceiling (with given payload) 3.9 km (12,800 ft) w/ 4kg, 2.2 km (7,200 ft) w/ 8.7 kg


Physical Features

Diagonal Size (propeller center to center) 1,025 mm 40.4 inches
Unfolded Size (flight ready, WxLxH) 165.5 x 154 x 76.5 cm 65.1 x 60.6 x 30.2 inches
Folded Size (stow, WxLxH) 47.5 x 49.5 x 47 cm 18.7 x 19.5 x 18.5 inches
Empty Weight (w/o batteries) 7.8 kg 17.2 lbs
Weight w/ Batteries 16.3 kg 35.9 lbs
Max Gross Takeoff Weight 25 kg 55 lbs
Max Payload Capacity 8.7 kg 19.1 lbs
Transport Case Size (WxLxH) 64.8 x 64.8 x 58.4 cm 25.5 x 25.5 x 23.0 inches
Transport Case Weight (w/ aircraft) 29 kg 64 lbs


Flight Stack

Flight Controller CubePilot Cube Blue H7 Triple Redundant IMUs
GNSS / Compass CubePilot Here3 M8P (2x)
Payload Power Rails 5v, 12v/15v, 18v, 44.4v (12s battery voltage)
Payload Interface IFT Universal Payload Interface V2.1
Operating Software Copter by Ardupilot


Flight Modes

Position Hold Holds altitude and position, manual roll and pitch
Loiter Holds altitude and position, precision manual movements using GPS
Auto Executes pre-defined mission
RTL Auto returns to takeoff location and lands
Land Auto land while maintaining position
Altitude Hold Holds altitude only, failsafe mode if GPS signal lost
