Description
UgCS Expert
Main Features:
-
Waypoints, Linear, Circle, Perimeter, Area Scan tools
- LiDAR Toolset
-
Automatic Photogrammetry, Vertical (Facade) scan, Corridor mapping, SAR tools
-
Immersive 3D mission planning environment
-
KML/CSV data import
-
DEM import
-
Elevation profile & Terrain following mode
-
Geo-referenced image import
-
Custom map overlays
-
ADS-B Receiver
-
Video Transmitting
-
Compatible with UgCS Mapper to process images and create map overlays.
LiDAR Toolset Key Features:
Precise calibration
Increase the accuracy of laser data with automated IMU calibration commands.
UgCS supports the two most popular IMU calibration patterns: Eight-figure and U-figure
Flight patterns for route planning
Based on the area of your interest, set up LIDAR Area scanning for areas like construction sites, open-pit mines, and forests, or employ LIDAR Corridor scanning for linear objects like power lines or pipelines
Anti-shake turns
Reduce shaking of the sensor, while accurately following the trajectory, with bank or loop turns applied automatically
Constant line spacing and buffer
Automatically calculate required line spacing and overlap to ensure desired point cloud density and improve coverage on area borders
SUPPORTED DRONES AND AUTOPILOTS:
- Matrice 600/600 Pro
- Matrice 300
- Matrice 200/210/210RTK
- Matrice 100
- Inspire 2
- Inspire 1/1 Pro/Raw
- Phantom 4 RTK (SDK RC only)
- Phantom 4/4 Pro (excluding Agro)
- Phantom 3
- Mavic Pro/2 series
- Spark
- A3/N3
- ANAFI
- Ardupilot
- Px4
- and other
Autel
- EVO II (mission export for Autel Explorer)
Mikrokopter
- Micropilot
License overview:
- one user
- one-time purchase
- includes first year support
UGCS SYSTEM REQUIREMENTS
Operating system:
Windows 7 with SP1 or later; Windows 8; Windows 10 / 64-bit
Mac OS X Maverick 10.9 or later / 64-bit
Linux: Ubuntu 18.04 LTS / 64-bit
CPU
Core 2 Duo or Athlon X2 at 2.4 GHz
Memory
Recommended RAM: 4GB or more
Graphics hardware
Graphics card with DirectX 9 support (shader model 2.0). Any card made since 2004 should work
Hard drive
2 GB of free space
Minimum supported screen resolution: 1024x768
